A Business Partner of Renesas Electronics Corporation.

PG2185T6R

GaAs Integrated Circuit

SPDT Switch for 2 GHz to 6 GHz

D a t a S h e e t

R09DS0053EJ0300

Rev.3.00

Nov 22, 2012

DESCRIPTION

The PG2185T6R is a GaAs MMIC SPDT (Single Pole Double Throw) switch which was designed for 2 GHz to 6

GHz applications, including dual-band wireless LAN. This device can operate frequency from 2 GHz to 6 GHz, having

the low insertion loss and high isolation.

This device is housed in a 6-pin plastic TSSON (Thin Shrink Small Out-line Non-leaded) (T6R) package and is suitable

for high-density surface mounting.

FEATURES

<R>

Operating frequency : f = 2.0 to 6.0 GHz

Switch control voltage : V cont (H) = 1.8 to 3.6 V (3.0 V TYP.)

: V cont (L) = ? 0.2 to 0.2 V (0 V TYP.)

Low insertion loss : L ins 1 = 0.40 dB TYP. @ f = 2.0 to 2.5 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins 2 = 0.50 dB TYP. @ f = 2.5 to 6.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

High isolation : ISL1 = 26 dB TYP. @ f = 2.0 to 2.5 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: ISL2 = 25 dB TYP. @ f = 2.5 to 6.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

Handling power : P in (1 dB) = +30.5 dBm TYP. @ f = 2.5 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: P in (1 dB) = +30.5 dBm TYP. @ f = 6.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

High-density surface mounting : 6-pin plastic TSSON (T6R) package (1.0 × 1.0 × 0.37 mm)

APPLICATIONS

Wireless LAN (IEEE802.11a/b/g/n)

UWB, near field communications

ORDERING INFORMATION

Part Number

PG2185T6R-E2

Order Number

PG2185T6R-E2-A

Package

6-pin plastic

TSSON

(Pb-Free)

Marking

Supplying Form

Embossed tape 8 mm wide

Pin 1, 6 face the perforation side of the tape

Qty 5 kpcs/reel

Remark To order evaluation samples, please contact your nearby sales office.

Part number for sample order: PG2185T6R-A

CAUTION

Although this device is designed to be as robust as possible, ESD (Electrostatic Discharge) can damage this

device. This device must be protected at all times from ESD. Static charges may easily produce potentials of

several kilovolts on the human body or equipment, which can discharge without detection. Industry-standard

ESD precautions must be employed at all times.

The mark <R> shows major revised points.

The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.

R 0 9 D S 0 0 5 3 E J 0 3 0 0 R e v . 3 . 0 0

Nov 22, 2012

P a g e 1 o f 9
